Looking for detailed 1975 YZ360B transmission disassembly/assembly guide
Hi everyone, I have a 1975 YZ360B. The standard factory service manual doesn't show a detailed, step-by-step disassembly or assembly for the transmission cluster—it mostly just has basic diagrams.
Does anyone have a supplemental guide, workshop notes, or a detailed breakdown of the internal shimming, shift fork placement, and splitting order for this specific vertical-case engine? i just joined this group and the website is cool as all hell!


.jpg)

.png)













.jpg)

.png)
.png)
.png)






Hello Dave . . . This is probably not what you want to hear . . . but I'm not aware of any such "detailed" Yamaha service manual that deals specifically with your YZ360B transmission assembly.
Your engine was based off the earlier DT1 and RT1 models, with very similar construction and even shares some interchangeable parts ... but of course, most parts in the YZ's were performance upgrades suitable for racing.
I'm just saying, the basic layout and spacing is the same. Perhaps some of the earlier DT and or RT manuals would shed some light on the subject.
Also, you might find more detailed information in one of the aftermarket manuals such as Haynes or Clymer. Lastly, the parts manuals show the complete layout of all parts, and will probably be one of your best resources.
Good Luck
